Piattaforma

Moterra SL

Nome Modello

Moterra SL 2

Codice Modello

C65204U

KIT TELAIO

Telaio

Moterra SL, Series 1 Carbon construction, 150mm travel, Proportional Response Tuned Suspension, FlexPivot Chainstay, direct mount internal battery, engineered plastic skid plate, 55mm chainline, DirectLine internal cable routing, 29” FlipChip, 148x12mm Maxle thru-axle, UDH hanger, 200mm native post mount brake, 1-1/8” – 1.5” tapered headtube, angle adjust headset

Forcella

Fox Performance 36, 160mm travel, Grip Damper, 3-position adjust, 15x110mm Kabolt thru-axle, tapered steerer, 44mm offset

Serie sterzo

Acros Adjustable Angle (1.2°)

Rear Shock

Fox Float X Performance Elite, 2 pos adj, EVOL LV, 210x55mm

E-SYSTEM

Motore

Shimano EP801, 85Nm, Custom Tuned, Eco, Trail 1, Trail 2, Boost Modes

Batteria

Custom 601Wh battery

Carica batteria

Custom 4A

Display

Shimano SC-EM800 Cycle Computer, Bluetooth LE Compatible

Certifications

UL2849

TRASMISSIONE

Cambio

Shimano XT

Leve cambio

Shimano Deore M6100, 12-speed

Catena

Shimano Deore 6100, 12-speed

Guarnitura

e*thirteen e*spec Plus, 165mm, 34T

Pacco pignoni

Shimano Deore 6100, 10-51, 12-speed

FRENI

Freni

Magura MT5 4-piston hydraulic disc w/ Storm HC 203mm, 6-bolt rotors

Leve Freno

Magura MT5 hydraulic disc

RUOTE

Cerchi

WTB KOM Tough i30, 30mm inner width, TCS tubeless ready

Raggi

DT Swiss Champion

Dimensioni pneumatico

2.6

Dimensione Ruote

29

Mozzi

(F) Formula DC-71132h, 15x110mm / (R) DT Swiss 370 Hybrid, 32h, 12x148mm

Pneumatici

(F) Maxxis DHF, 29×2.5 “, 2C, EXO, tubeless ready / (R) Maxxis Dissector , 27.5×2.4”, 2C, EXO, tubeless ready

COMPONENTI

Manubrio

Cannondale 3 Riser, 6061 Alloy, 25mm rise, 8° sweep, 5° rise, 800mm

Attacco Manubrio

Cannondale 1, 7075 Alloy, 1-1/8″, 35mm, 0°

Impugnatura

Cannondale TaperRidge

Sella

Fizik Terra Ridon X5, 145mm, Wingflex, S-Alloy Mobius rail 7x7mm

Reggisella

Cannondale DownLow Dropper, internal routing, 31.6, 150mm (S), 170mm (M-XL)
